TECHNICAL DETAIL
Capacity & Working Table
Longitudinal traverse (X) 650 mm
Vertical traverse (Y) 500 mm
Transverse traverse (Z) 500 mm
Pallet Size 500 x 400 mm
No. of pallet 2 Nos.
Workpiece size (dia x height) Ø 500 x Height-650 mm
Indexing Position 1° x 360 division
Safe working load on table 375 Kgs
Pallet Change 180 Deg. Swing type
Type of Drive of Index table Servo Driven
Automatic Tool Changer
No. of Tools Minimum 24 Nos.
Maximum Tool Dia With Adjacent Package Min 75 mm / Min 120 mm
Maximum Tool Length Minimum 250 mm
Maximum Tool Weight Minimum 7 Kg
Tool Change Time(T- T) 3 Sec
ACCURACY
Linear Axis
Positional uncertainty/
deviation for all linear axes 0.01
Repeatability for all linear axes (Ps max) 0.006
Index Table
Positional uncertainty/ deviation 8 arc sec
Repeatability 6 arc sec
Spindle run out Within 0.005 mm at spindle nose and 0.015 (using mandrel) at 300 mm from spindle face
Feed drive- AC Servo drive
Cutting feed rate Minimum 15 m/min
Rapid feed rate Minimum 35 m/min
Spindle
Spindle Taper BT-40
Spindle Speed Minimum RPM 6000
Spindle power ( Contd./Intermitent) 11 /15 Kw
Spindle Bearing- Inner Dia. 80 mm
C N C Control System
Siemens simultaneous 3 axes CNC Control System, Ethernet feature/USB/ Flash card ports enable with all standard features or their latest applicable version with suitable technically justified standard features. Machine control system shall be capable of simultaneous interpolation of X,Y,Z axes
Standard Features
Roller Type Guide Ways for all linear axes
Precise ball screws for all linear axes
Electronic Counter Balance For The Vertical Axis
Automatic Centralize Lubrication System
AC Servo Drives For All Axes
Air Blast For Spindle Taper Clearing
Hydraulic Power Pack
Basic Coolant System With Scraper type Chip Conveyor & Chip Trolley
Lamella Covers On Linear Axes X & Y
Absolute Encoder Foe All Axes
10.4 inch color LCD Display
Backlash & Pitch Error Compensation
Rigid Tapping & Retract Function
Simultaneous Interpolation Upto 3 Axes
Linear, Circular & Helical Interpolation
Polar Co-ordinate Programming
Machine Alarm Diagnosis
Energy Saving Function
3- tier signal tower lamp
Machine Lamp
Coolant Gun
Ring Coolant around the Spindle
Automatic Pallet Changer
Index Table 1° x 360 division
Front Gauge Panel
Accessories/equipment of the machine – one set each
Automatic centralized lubrication system
Oil skimmer
Visible window on operator side
Build in control Panel A/C
Voltage Stabilizer of Suitable capacity
Full door with sliding door interlock
Machine light
Coolant system for coolant supply including pump
Stub Arbor to suit m/c - 1 number
Collet Adaptor (ER 32) to suit m/c - 1 number
Collet Ø20 mm (ER 32) suitable to m/c
|
