TECHNICAL DETAIL
Material which can be drill: Cast Iron Steel
Nature of Duty of Operation of Drill machine: Light Duty
Feed Range in mm/rev: 0.125 - 1.25
Number of feed: 6
Number of Spindle speed: 12
Taper in Spindle as per IS 2582-1972 with Latest amendment: MT 4
Range of Spindle Speed in Forward Direction in rev/min: 50-1750
Main Motor Power in kW: 2
Arm motor power in kW: 0.75
Type of Cooling: Air cooling
Main Spindle Bearing confirming Pre-loaded Standard make hint: Spindle Bearing High precision class Double Row taper roller bearings at Front & Single Row taper roller bearing at back: No
Power supply: Single Phase Supply (230 V, 50 Hz)
Warranty in years: 1
Coolant Pump output in kw as per IS 2161:1962 latest: 0.11
Sleeve Travel Type: Manual
Tapping in steel - metric fine threads: M20
Type of Lubrication: Oil recirculating
Taping in cast Iron: M30
Maximum Drill Diameter for steel in mm: 32
Maximum Drill Diameter for cast iron in mm: 32
Maximum Drill Diameter for non ferrous material in mm: N/A
Maximum Quill Traverse in mm: 200
Column Sleeve Diameter in mm: 200
Width of Arm Guide Ways in mm: 175
Maximum Drilling Radius in mm with tolerance ± 10 mm: 1200
Minimum Drilling Radius in mm: 500
Maximum Length of Bed in mm with tolerances ± 50 mm: 650
Maximum Width of Bed in mm with tolerance ± 50 mm: 600
Maximum Drill head traverse in mm with tolerance ± 50 mm: 750
Arm Traverse in mm with tolerance ± 30 mm: 450
Spindle travel (drilling depth) in mm with tolerance ± 10 mm: 200
Maximum Distance from Base plate to spindle in mm with tolerances ± 50 mm: 970
Minimum distance from Base plate to spindle in mm: 350
Travel of Sleeve in mm: 250
Lead Screw Diameter in mm: 25
Lead Screw Pitch in mm: 6
Universal table for 32 mm drill capacity: Yes
Universal table for 40 mm drill capacity: No
Universal table for 50 mm drill capacity: No
Universal table for 60 mm drill capacity: No
Machine Vice with fixed base 80 mm clamping range 0-50 mm pull type: No
Machine Vice with fixed base 80 mm clamping range 0-50 mm push type: No
Machine Vice with fixed base 160mm clamping range 0-100 mm pull type: Yes
Machine Vice with fixed base 160 mm clamping range 0-100 mm push type: Yes
Machine Vice with fixed base 315 mm clamping range 0-200 mm pull type: No
Machine Vice with fixed base 315 mm clamping range 0-200 mm push type: No
Machine Vice with Swivel base 80 mm clamping range 0-50 mm push type: No
Machine Vice with Swivel base 160 mm clamping range 0-100 mm pull type: No
Machine Vice with Swivel base 160mm clamping range 0-100 mm push type: No
Machine Vice with Swivel base 315mm clamping range 0-200 mm push type: No
Machine Vice with Swivel base 315mm clamping range 0-200 mm pull type: No
Suitable Tapping Attachment drill capacity 32 mm: Yes
Suitable Tapping Attachment drill capacity 40 mm: No
Suitable Tapping Attachment drill capacity 50 mm: No
Suitable Tapping Attachment drill capacity 60 mm: No
Drill chuck quick change 32 mm: Yes
Drill chuck quick change 40 mm: No
Drill chuck quick change 50 mm: No
Drill chuck quick change 60 mm: No
Boring Head 32mm: Yes
Boring Head 40mm: No
Boring Head 50mm: No
Boring Head 60mm: No
Co-ordinate table 32 mm: No
Co-ordinate table 40mm: No
Box Table 32 mm: No
Box Table 40 mm: No
Box Table 50 mm: No
Drill drift 4 number: No
Quick indexing dividing head: NO
Availability of Test Report from Central Govt/NABL/ILAC acredited lab to prove Conformity to specification: NO
Copies of test report to be furnished to the buyer on demand at the time of supplies: No
|
