Moulding specimens of Concrete is an important activity and good specimen can be achieved only if the cement paste covers the aggregate thoroughly and uniformly before pouring the concrete mix into standard moulds. The object of efficient mixing can be most satisfactorily achieved in Pan Mixers.

These mixers have been designed and developed to mix both dry & wet materials. Manually controlled mixers are rotated by a turntable which is driven by an electric motor. The mixing pan is removable and can be tilted for easy emptying of the material. The mixing blades and paddle are made of special steel for fast and effective mixing operation and are long lasting to withstand wear & tear. Mounted on a sturdy but light Steel frame, they can be easily moved about on wheels.

 Pan type ,min. 40L capacity, Material of Construction: low carbon mild steel, Hardness of platen: 50RHC, efficient mixing in dry and wet conditions. Suitable for aggregate size upto 20mm. The drum is driven off the ribbed base. The lid with mixing paddles clears off the top of the drum to provide maximum access to operator. Overall Dimension: 910mm x 875mm x1250mm, Motor: 2HP, 960rpm, Adjustable blades, Suitable for operation on 440V, 50 Hz, 3 phase, AC Supply

 Safety features

single phase preventer

Cover for Operator Safety

Load over load relay
