| ACCELERATED CARBONATION CHAMBER- Carbonation Chamber for Accelerated Carbonation test of Concrete. Supplied complete with Prism Mould 100mm X 100mm X 200mm (5Nos), Attachment for Splitting 100 mm cube,150 mm cube, 100mm X 100mm X 200 mm prism. Supplied complete with 30 kg CO2 Cylinder (for within India Supply only).
TECHNICAL SPECIFICATION:
? Construction: Sandwich Type-Double walled
? Inner chamber: Mirror polished Stainless Steel S.S.-304
? Exterior body: Mild Steel
? Thermal Insulation: 75mm to prevent thermal loss
? Exterior Body Paint: Powder coating in attractive shades.
? Chamber Dimensions: 600×600×600mm(W×D×H)
? Chamber volume: 216 Liters
? Optimum performance: With 150Kgs of Concrete Load.
? CO2 Concentration: Atmosphere concentration to 4.5% with accuracy 0.01% (Maximum solubility of CO2 in water is 4%).
? Temperature range: 10°C-70°C
? Temperature accuracy: ±0.5°C
? Temperature Resolution: 0.1°C
? Temperature Uniformity: 2°C
? Temperature sensor: Through Pt-100 type RTD sensor.
? No. of Temperature sensor: 01 number.
? Humidity range: 40% RH to 90% RH
? Humidity accuracy: ±2% RH
? Humidity Uniformity: ±3% RH
? Humidity Measurement: Through Capacitance type RH Sensor.
? No. of RH Sensors: 01 number.
? Temperature & RH Control Indicator: Microprocessor based AUTO-TUNE Digital PID Controller.
? Chamber II Iumination: With 1 LED lights for lesser power consumption.
? Mobility: On castor wheels.
Power Supply: 230Volts, 50Hz, Single Phase, AC Supply. |
